Metal Ridge Cap Roll Forming Machine2

  • Tags:Metal Ridge Cap Roll Forming Machine

  • Related Video:

Product Information

APPLICATION:
Metal ridge cap is recommended to prevent water, rain or snow leakage, for industrial and residential applications, enjoying simple installation. Ridge-stepping on cap is making match with step tile. Metal ridge cap roll forming machine is the essential for its production.

FEATURES:
1.Hydraulic Decoiler with Break is equipped for roll forming production, not manual one.
2.Refine steel plates in 22 – 25 mm as Sidewall of machine is used.
3.12 – 16 Nos of Rollers is used for ridge cap forming, ensuring profile strength.
4.Step forming by AC Motor is adopted for its ridge stepping.
5.Mitsubishi (Japan) PLC and 5.7' Touchable Screen are used for for data processing and setting.
6.Roll forming speed is 2 – 12 meters / minute.

TECHNICAL PARAMETER
T SHAPE CORRUGATED SHEET ROOF PANEL ROLL FORMING MACHINE
(1)Suitable Material:  PPGI Coil
(2)Material Thickness: 0.40 -- 0.80 mm

Production Process:
decoiling – roll forming – stepping – cut-off after sizing – final ridge cap

Composition:
1.3 tons hydraulic decoiler: 600 mm width; ? 500 – 600 mm inner diameter; 2.0 kw
2.Roll forming machine: 12 – 16 Nos roller station; ? 60 mm main shaft; 22 – 25 mm machine sidewall thickness; 2 – 12 meters / minute
3.Hydraulic step forming & cutting-off: Gr12 steel blade; 15 tons working table pressure; with fan-cooler; 4 kw
4.Simple run-out table: 4 pieces, in 8# channel steel
5.PLC controller: Mitsubishi PLC; 5.7" Mitsubishi touchable screen; Japanese frequency converter; Schneider electronic components
